FEATURES
100% air powered operation
Intrinsically safe
No internal workings
High vacuum and high airflow
Fully automatic operation
Can be fitted to any piping configuration
Robust construction
Ideal for use in confined spaces
Also available in Class 3 carbon, 316 stainless steel or polyurethane coated tanks

TECHNICAL DATA
Height 60 cm
Width 50 cm
Weight 145 kg
Air consumption 100-280CFM at 85psi to 100psi+
Up to 25”Hg+ (85kPa) vacuum
Suction inlet and Discharge outlet 75 mm (3”) 100 mm (4”)
Discharge outlet 100 mm (4”)
Handles solids to 50 mm (2”)

FEATURES
High volume transfers up to 60m3/hr @SG1.0(264USGPM)
No internal workings
A one man manual or automatic operation
Optional 400, 600 and 750cfm jet packs available
No moving parts in contact with product
Dual fork/crane frame standard
Optional exhaust air box available

TECHNICAL DATA
Height 158cm
Width 100cm
Length 186cm
Weight 1200kg
Air consumption 600cfm@85psi to 100psi
Suction inlet 100mm (4”)
Dual discharge outlets 100mm (4”)
Handles solids to 70mm (3”)

FEATURES
100% compressed air operation
Intrinsically safe
Manual or fully automatic operation
Robust construction and low wear characteristics
High vacuum and high airflow
Delivers up to 1000 metres (3280ft) horizontally and 35 metres (115ft) vertically
High solids content transfer
TECHNICAL DATA
Height 151 cm
Width 138 cm
Length 130 cm
Weight 720 kg
Air consumption 600cfm at 85psi to 100psi
Up to 25”Hg+ (85kPa) vacuum
Suction inlet 100mm (4”), plus 4” Gravity feed option
Discharge outlet 100mm (4”)
Handles solids to 70mm (3”)

FEATURES
100% compressed air operation
Intrinsically safe
Manual or fully automatic operation
High vacuum and high airflow
Throughput capacity up to 30 m3/hr @SG1.0(132USGPM)
Variable air consumption 150-750cfm
Robust and compact
Gravity feed capability
Roll cage and weather cover (optional)

TECHNICAL DATA
Height 165 cm
Width 129 cm
Length 120 cm
Weight 680 kg
Air consumption 150-270-400-600-750CFM at 85psi to 100psi
Up to 25”Hg (85kPa)+ vacuum
Fork skid mounted
Suction inlet 100 mm (4”)
Discharge outlet 100 mm (4”)
Handles solids to 75 mm (3”)
Also available in Class 3 carbon, 316 stainless steel or polyurethane coated tanks

FEATURES
100% compressed air operation
Intrinsically safe
Versatile
No internal moving components
Fully automatic
High vacuum and high airflow
Delivers up to 500 metres (1640 feet)
High solids content transfer
Also available in 316 stainless steel

TECHNICAL DATA
Height 110 cm
Width 70 cm
Length 90 cm
Weight 198 kg
Air consumption 150cfm at 85psi to 100psi
Up to 25”Hg+ (85kPa) vacuum
Suction inlet 75 mm (3”)
Discharge outlet 75 mm (3”)
Handles solids to 50 mm (2”)

FEATURES
100% compressed air operation
Intrinsically safe
Fully automatic
High vacuum and high airflow
Delivers up to 1000 metres
Skid mounted, wheel mounted or skid mounted with roll frame
Robust construction

TECHNICAL DATA
Height 135 cm
Width 66 cm
Length 131 cm
Weight 330 kg
Air consumption minimum 280CFM at 85psi to 100psi
Up to 25”Hg (85kPa)+ vacuum
Suction inlet 100 mm (4”)
Discharge outlet 100 mm (4”)
Handles solids to 75 mm (3”)
Also available in Class 3 carbon, 316 stainless steel or polyurethane coated tanks
Wheel mounted option available
